Com um sensor MOS de 20,1 MP de 1 ", podem ser tiradas fotos de alta resolução e vídeo UHD 4030p. O design do sensor oferece uma sensibilidade máxima de ISO 25600 para permitir trabalhos com pouca luz e uma taxa de captura de 10 fps superior também complementando a versatilidade do sensor, há uma lente Leica DC Vario-Elmar com zoom óptico de 15x, que cobre uma faixa de comprimento focal equivalente a 24-360mm para fotografar em uma ampla variedade de situações.O alcance dessa lente é beneficiado pelos 5 eixos estabilização ótica de imagem, que minimiza a aparência da câmara para imagens mais nítidas ao trabalhar.
| Lens |
Leica DC Vario-Elmar 3.3 - 6.4 / 8.8 – 132mm ASPH., 35mm camera equivalent: 24 - 360mm,
aperture range: 3.3 – 8 / 6.4 - 8 (at 8.8 / 360mm) |
| Optical Image stabilization |
Optical 5-axis compensation system |
| Focusing range |
| AF |
Maximum wideangle setting: 0.5m/ 1‘6“ to 8. Maximum telephoto setting: 1m/ 3‘3“ to 8. |
| AF Macro / MF / Snapshot Modes / Motion Pictures |
Maximum wideangle setting: 3cm/ 13/16“ to 8. Maximum telephoto setting: 1m/ 3‘3“ to 8. |
| Image sensor |
1“ MOS sensor. Primary color filter.
Total pixel number: 20,900,000. Effective pixels: 20,100,000. |
| Minimum Illuminance |
approx. 10lx (when i-Low light is used, the shutter speed is 1/30 s) |
| Shutter system |
Electronically and mechanically controlled |
| Shutter speeds |
| Still pictures |
T (max. approx. 120s),
60 - 1/2000 s (with the mechanical shutter)
1 - 1/16000 s (with the electronic shutter) |
| Motion pictures |
1/30* - 1/16000 s
1/2 - 1/16000 s (When [Exposure Mode] is set to [M] in Creative Video Mode and [MF] is selected)
An uninterrupted motion picture take cannot be longer than 29 minutes, regardless of the circumstances, e.g.the respective settings. In the case of 4K videos, the time limit is 15 minutes.
* Differs according to frame rate |
| Series exposure |
| Continuous series exposure frequency |
With Electronic /Mechanical shutter: 2fps (L) / 7fps (M) / 10fps (H) |
| Number of serially recordable pictures |
With RAW files: 28 or more*
Without RAW files: 85 or more*
* Based on CIPA standards and a card with a fast read/write speed |
| Exposure |
| Exposure control modes |
Program (P), Aperture-priority (A),
Shutter-priority (S),Manual setting (M) |
| Exposure compensation |
±5EV in 1/3 EV steps |
| Exposure metering modes |
Multi-zone, center-weighted, spot |
| Recording file formats |
| Still pictures |
RAW/JPEG (based on “Design rule for Camera File system” and on the “Exif 2.31” standard) |
| Motion pictures (with audio) |
[MP4]
3840x2160/30p (100 Mbit/s)
3840x2160/24p (100 Mbit/s)
1920x1080/60p (28 Mbit/s)
1920x1080/30p (20 Mbit/s)
1280x720/30p (10 Mbit/s) |
| Audio recording format |
AAC (2ch) |
| Monitor |
3.0“ TFT LCD, resolution: approx. 1,240,000 dots,
field of view: approx. 100%, aspect ratio: 3:2,
touch screen functionality |
| Viewfinder |
0.21“ LCD viewfinder,
resolution: approx. 2,330,000 dots,
field of view: approx. 100%, aspect ratio: 3:2,
with diopter adjustment -4 to +3 diopters, Magnification:approx. 1.45x / 0.53x (35mm camera equivalent with 50mm lens at infinity; -1.0 m-1),
eye sensor |
| Flash |
Built-in pop up flash
AUTO, AUTO/Red-Eye Reduction, Forced ON, Forced ON/Red-Eye Reduction, Slow Sync.,
Slow Sync./Red-Eye Reduction, Forced OFF |
| Recording media |
SD / SDHC* /SDXC* memory cards,
(*UHS-I/UHS Speed Class 3) |
| Wi-Fi |
| Compliance standard |
IEEE 802.11b/g/n (standard wireless LAN protocol) |
| Frequency range used (central frequency) |
2412- 2462MHz (1 to 11ch),
maximum output power: 13dBm (EIRP) |
| Encryption method |
Wi-Fi compliant WPA™ / WPA2™ |
| Access method |
Infrastructure mode |
| Bluetooth function |
| Compliance standard |
Bluetooth Ver. 4.2 (Bluetooth low energy (BLE)) |
| Frequency range used (central frequency) |
2402 to 2480MHz,
maximum output power: 10dBm (EIRP) |
| Operating temperature/ humidity |
0 - 40°C (32 - 104°F) / 10 - 80% RH |
| Power Consumption |
1.8W/2.8W (When recording with monitor/viewfinder)
1.6W/1.6W (When playing back with monitor/viewfinder) |
| Terminals / Interfaces |
[HDMI]: Micro HDMI Type D
[USB/CHARGE]: USB 2.0 (High Speed) Micro-B |
| Dimensions (W x H x D) |
approx. 113 x 67 x 46mm / 47/16 x 27/32 x 113/16“ |
| Weight |
approx. 340g / 12oz |
