Technical Specification
Tipo
Digital camera with support for interchangeable lenses
Montagem da objetiva
Nikon Z mount
Sensor de imagem
FX, CMOS, 35.9 mm x 23.9 mm
Total de pixels
52.37 million
Sistema de redução de poeira
Image sensor cleaning, Image Dust Off reference data (requires NX Studio)
Pixels efetivos
45.7 million
Tamanho da imagem (pixels)
[FX (36 x 24)] selected for image area:
(L) 8256 x 5504 ( 45.4 million)
(M) 6192 x 4128 ( 25.6 million)
(S) 4128 x 2752 ( 11.4 million)
[DX (24 x 16)] selected for image area:
(L) 5392 x 3592 ( 19.4 million)
(M) 4032 x 2688 ( 10.8 million)
(S) 2688 x 1792 ( 4.8 million)
[1:1 (24 x 24)] selected for image area:
(L) 5504 x 5504 ( 30.3 million)
(M) 4128 x 4128 ( 17.0 million)
(S) 2752 x 2752 ( 7.6 million)
[16:9 (36 x 20)] selected for image area:
(L) 8256 x 4640 ( 38.3 million)
(M) 6192 x 3480 ( 21.5 million)
(S) 4128 x 2320 ( 9.6 million)
Formatos de ficheiro
NEF (RAW): 14 bit; choose from lossless compression, high efficiency (high), and high efficiency options
JPEG: JPEG-Baseline compliant with fine (approx. 1 : 4), normal (approx. 1 : 8), or basic (approx. 1 : 16) compression; size-priority and optimal-quality compression available
HEIF: Supports fine (approx. 1 : 4), normal (approx. 1 : 8), or basic (approx. 1 : 16) compression; size-priority and optimal-quality compression available
NEF (RAW)+JPEG: Single photograph recorded in both NEF (RAW) and JPEG formats
NEF (RAW)+HEIF: Single photograph recorded in both NEF (RAW) and HEIF formats
Sistema Picture Control
Auto , Standard , Neutral , Vivid , Monochrome , Portrait , Landscape , Flat
Creative Picture Controls (Dream, Morning, Pop, Sunday, Somber, Dramatic, Silence, Bleached, Melancholic, Pure, Denim, Toy, Sepia, Blue, Red, Pink, Charcoal, Graphite, Binary, Carbon); selected Picture Control can be modified; storage for custom Picture Controls
Note: Choice of Picture Controls is restricted to Standard, Monochrome, and Flat when HLG is selected for tone mode during still photography.
Suportes
CFexpress (Type B) , XQD , SD , SDHC (UHS-II compliant) , SDXC (UHS-II compliant)
Ranhura dupla para cartões
1 CFexpress card or XQD card and 1 Secure Digital (SD) card
Either card can be used for overflow or backup storage, for separate storage of NEF (RAW) and JPEG or HEIF pictures, or for storage of duplicate JPEG or HEIF pictures at different sizes and image qualities; pictures can be copied between cards.
Sistema de ficheiros
DCF 2.0, Exif 2.32, MPEG-A MIAF
Visor
1.27-cm/0.5-in. approx. 3690k-dot (Quad VGA) OLED electronic viewfinder with color balance, auto and 18-level manual brightness controls, and support for high frame rates
Cobertura da imagem no visor
Approx. 100% horizontal and 100% vertical
Ampliação do visor
Approx. 0.8x (50 mm lens at infinity, -1.0 m-1)
Ponto de visão do olho
23 mm (-1.0 m-1; from rearmost surface of viewfinder eyepiece lens)
Ajuste dióptrico
-4 - +3 m-1
Sensor de movimento ocular
Automatically switches between monitor and viewfinder displays
Objetivas compatíveis
Z mount NIKKOR lenses
F mount NIKKOR lenses (mount adapter required; restrictions may apply)
Obturador
Electronic shutter with shutter sound and sensor shield
Velocidade do obturador
1/32000 to 30 s (choose from step sizes of 1/3, 1/2, and 1 EV, extendable to 900 s in mode M), bulb, time
Velocidade de sincronização do flash
Flash synchronizes with shutter at speeds of 1/250 or 1/200 s; or slower (but note that the guide number drops at speeds of 1/200 to 1/250 s); sync speeds as fast as 1/8000 s are supported with auto FP high-speed sync
Modo de obturação
Single frame , continuous low-speed , continuous high-speed , high-speed frame capture (with Pre-Release Capture) , Self-timer
Approximate frame advance rate
Up to 120 fps
Continuous low-speed: Approx. 1 to 10 fps
Continuous high-speed: Approx. 10 to 20 fps
High-speed frame capture (C30): Approx. 30 fps
High-speed frame capture (C60): Approx. 60 fps
High-speed frame capture (C120): Approx. 120 fps
Maximum frame advance rate as measured by in-house tests.
Autotemporizador
2 s, 5 s, 10 s, 20 s; 1 to 9 exposures at intervals of 0.5, 1, 2, or 3 s
Sistema de Exposímetro
TTL metering using camera image sensor
Exposure Metering mode
Matrix metering
Center-weighted metering: Weight of 75% given to 12 or 8 mm circle in center of frame or weighting can be based on average of entire frame
Spot metering: Meters circle with a diameter of approximately 4 mm centered on selected focus point
Highlight-weighted metering
Gama de Exposímetro
-3 to +17 EV
Figures are for ISO 100 and f/2.0 lens at 20 °C/68 °F
Modos de exposição
P: programmed auto with flexible program, S: shutter-priority auto, A: aperture-priority auto, M: manual
Compensação de exposição
-5 to +5 EV (choose from step sizes of 1/3 and 1/2 EV)
Bloqueio da exposição
Luminosity locked at detected value
Sensibilidade ISO (Índice de exposição recomendado)
ISO 64 to 25600 (choose from step sizes of 1/3 and 1 EV); can also be set to approx. 0.3, 0.7, or 1 EV (ISO 32 equivalent) below ISO 64 or to approx. 0.3, 0.7, 1, or 2 EV (ISO 102400 equivalent) above ISO 25600; auto ISO sensitivity control available
Note: ISO sensitivity is limited to 400 to 25600 when HLG is selected for tone mode.
D-Lighting ativo
Auto, Extra high 2, Extra high 1, High, Normal, Low, and Off
Exposição múltipla
Add, average, lighten, darken
Outras opções
HDR overlay, photo mode flicker reduction, high-frequency flicker reduction
Sistema de focagem automática
Hybrid phase-detection/contrast AF with AF assist
Gama de deteção
-7 to +19 EV (-9 to +19 EV with starlight view)
Measured in photo mode at ISO 100 and a temperature of 20 °C/68 °F using single-servo AF (AF-S) and a lens with a maximum aperture of f/1.2
Servo da objetiva
Autofocus (AF):
Single-servo AF (AF-S) , Continuous-servo AF (AF-C) , full-time AF (AF-F; available only in video mode)
; predictive focus tracking
Manual focus (M):
Electronic rangefinder can be used
Ponto de focagem
493
Number of focus points available in photo mode with single-point AF selected for AF-area mode and FX selected for image area
Modo de área de AF
Pinpoint (available in photo mode only), single-point, dynamic-area (S, M, and L; available in photo mode only), wide-area (S, L, C1, and C2), and auto-area AF; 3D-tracking (available in photo mode only); subject-tracking AF (available in video mode only)
Bloqueio de focagem
Focus can be locked by pressing shutter-release button halfway (single-servo AF/AF-S) or by pressing the center of the sub-selector
Camera on-board VR
5-axis image sensor shift
Lens on-board VR
Lens shift (available with VR lenses)
Controlo de flash
TTL: i-TTL flash control; i-TTL balanced fill-flash is used with matrix, center-weighted, and highlight-weighted metering, standard i-TTL fill-flash with spot metering
Modos de flash
Front-curtain sync, slow sync, rear-curtain sync, red-eye reduction, red-eye reduction with slow sync, off
Compensação do flash
-3 to +1 EV (choose from step sizes of 1/3 and 1/2 EV)
Indicador de flash preparado
Lights when optional flash unit is fully charged; flashes as underexposure warning after flash is fired at full output
Sapata de acessórios
ISO 518 hot-shoe with sync and data contacts and safety lock
Sistema de iluminação criativa (Creative Lighting System, CLS) da Nikon
i-TTL flash control, radio-controlled Advanced Wireless Lighting, optical Advanced Wireless Lighting, modeling illumination, FV lock, Color Information Communication, auto FP high-speed sync, unified flash control
Equilíbrio de brancos
Auto (3 types), natural light auto, direct sunlight, cloudy, shade, incandescent, fluorescent (3 types), flash, choose color temperature (2500 to 10,000 K), preset manual (up to 6 values can be stored), all with fine-tuning
Tipos de bracketing
Exposure and/or flash , white balance , ADL
Video Metering system
TTL metering using camera image sensor
Metering mode
Matrix, center-weighted, or highlight-weighted
Frame size (pixels) and frame rate
7680 x 4320 (8K UHD): 30p (progressive)/25p/24p
3840 x 2160 (4K UHD): 120p/100p/60p/50p/30p/25p/24p
1920 x 1080: 120p/100p/60p/50p/30p/25p/24p
Note: Actual frame rates for 120p, 100p, 60p, 50p, 30p, 25p, and 24p are 119.88, 100, 59.94, 50, 29.97, 25, and 23.976 fps respectively.
Video Frame size (pixels) and frame rate (RAW video)
8256 x 4644: 60p/50p/30p/25p/24p
5392 x 3032: 60p/50p/30p/25p/24p
4128 x 2322: 120p/100p/60p/50p/30p/25p/24p
3840 x 2160: 120p/100p/60p/50p
Note: Actual frame rates for 120p, 100p, 60p, 50p, 30p, 25p, and 24p are 119.88, 100, 59.94, 50, 29.97, 25, and 23.976 fps respectively.
Video File format
NEV , MOV , MP4
Compressão do vídeo
N-RAW (12 bit) , Apple ProRes RAW HQ (12 bit) , Apple ProRes 422 HQ (10 bit) , H.265/HEVC (8 bit/10 bit) , H.264/AVC (8 bit)
Formato de gravação
Linear PCM (48 KHz, 24 bit, for videos recorded in NEV or MOV format) , AAC (48 KHz, 16 bit, for videos recorded in MP4 format)
Filmagem - dispositivo de gravação de áudio
Built-in stereo or external microphone with attenuator option; sensitivity adjustable
Video Exposure compensation
-3 to +3 EV (choose from step sizes of 1/3 and 1/2 EV)
Video ISO sensitivity (Recommended Exposure Index)
Mode M: Manual selection (ISO 64 to 25600; choose from step sizes of 1/6, 1/3 and 1 EV); with additional options available equivalent to approximately 0.3, 0.7, 1, or 2 EV (ISO 102400 equivalent) above ISO 25600; auto ISO sensitivity control (ISO 64 to Hi 2.0) available with selectable upper limit
Modes P, S, A: Auto ISO sensitivity control (ISO 64 to Hi 2.0) with selectable upper limit
Note: ISO sensitivity is limited to 400 to 25600 when HLG is selected for tone mode.
Video Active D-Lighting
Extra high, High, Normal, Low, and Off
Other options (video)
Time-lapse video recording, electronic vibration reduction, time codes, N-Log and HDR (HLG) video, wave-form display, red REC frame indicator, video recording display zoom (50%, 100%, and 200%), extended shutter speeds (mode M), and dual-format (proxy-video) recording for RAW video; extended oversampling available; option to view video recording info available via i menu; Hi-Res Zoom
Monitor size
8 -cm ( 3.2 –in.) diagonal
Monitor
vertically and horizontally tilting TFT touch-sensitive LCD with 170° viewing angle, approximately 100% frame coverage, and color balance and 15-level manual brightness controls
Monitor resolution
Approx. 2100 k-dot
Reprodução
Full-frame and thumbnail (up to 4, 9, or 72 pictures) playback with playback zoom, playback zoom cropping, video playback, slide shows, histogram display, highlights, photo information, location data display, auto picture rotation, picture rating, voice memo recording and playback, IPTC information embedding and display, filtered playback, skip to first shot in series, series playback, save consecutive frames, and motion blend
USB
Type C USB connectors
USB data connector (SuperSpeed USB) x1
USB Power Delivery connector x1
Saída por HDMI
Entrada de áudio
Stereo mini-pin jack (3.5 mm diameter; plug-in power supported)
Saída de áudio
Stereo mini-pin jack (3.5 mm diameter)
Terminal de 10 pinos para controlo remoto
Built-in (can be used with MC-30A/MC-36A remote cords and other optional accessories)
Wi-Fi "NIJ"
Standards:
IEEE802.11b/g/n/a/ac
Operating frequency:
2412 to 2472 MHz (channel 13), 5180 to 5700 MHz
Maximum output power (EIRP):
2.4 GHz band: 1.4 dBm
5 GHz band (5180 to 5320 MHz): 10.8 dBm
5 GHz band (5500 to 5700 MHz): 7.8 dBm
Authentication:
Open system, WPA2-PSK, WPA3-SAE
Wi-Fi "NICS"
Standards:
IEEE 802.11b/g/n/a/ac
Operating frequency:
2412 to 2472MHz (channel 13), 5150 to 5350 MHz and 5725 to 5850 MHz
Maximum output power (EIRP):
2.4 GHz band: 1.4 dBm
5 GHz band (5180 to 5320 MHz): 10.8 dBm
5 GHz band (5500 to 5825 MHz): 7.8 dBm
Authentication:
Open system, WPA2-PSK, WPA3-SAE
Wi-Fi "NIKC"
Standards:
IEEE 802.11b/g/n/a/ac
Operating frequency:
2412 to 2472 MHz (channel 13), 5180 to 5825 MHz (5180 to 5700MHz and 5745 to 5825 MHz)
Maximum output power (EIRP):
2.4 GHz band: 1.4 dBm
5 GHz band (5180 to 5320 MHz): 10.8 dBm
5 GHz band (5500 to 5825 MHz): 7.8 dBm
Authentication:
Open system, WPA2-PSK, WPA3-SAE
Wi-Fi "Others"
Standards:
IEEE 802.11b/g/n (Africa, the Middle East (other than Israel), Taiwan, Bangladesh, Pakistan, and Bolivia)
IEEE 802.11b/g/n/a/ac (other countries in the Asia, Europe, Israel, Australia, New Zealand, the Republic of Fiji, U.S.A., Canada, and Mexico)
IEEE 802.11b/g/n/a (other countries in the Americas)
Operating frequency:
Europe (excluding the countries listed below), Israel, and Turkey: 2412 to 2472 MHz (channel 13) and 5180 to 5825 MHz (5180 to 5700 MHz and 5745 to 5825 MHz)
Russia, Belarus, Kazakhstan, and Ukraine: 2412 to 2462 MHz (channel 11) and 5180 to 5320 MHz
Australia, New Zealand, and the Republic of Fiji: 2412 to 2462 MHz (channel 11) and 5180 to 5825 MHz (5180 to 5580 MHz, 5660 to 5700 MHz, and 5745 to 5825 MHz)
U.S.A., Canada, and Mexico: 2412 to 2462 MHz (channel 11) and 5180 to 5825 MHz (5180 to 5240 MHz, 5500 to 5580 MHz, 5660 to 5700 MHz, and 5745 to 5825 MHz)
Other countries in the Americas: 2412 to 2462 MHz (channel 11) and 5180 to 5805 MHz (5180 to 5240 MHz and 5745 to 5805 MHz)
Asia (other than Turkey, Kazakhstan, Taiwan, Bangladesh, Pakistan, and India), and New Caledonia: 2412 to 2462 MHz (channel 11) and 5745 to 5805 MHz
India: 2412 to 2472 MHz (channel 13) and 5180 to 5825 MHz (5180 to 5320 MHz and 5745 to 5825 MHz)
Africa, the Middle East (other than Israel), Taiwan, Bangladesh, Pakistan, and Bolivia: 2412 to 2462 MHz (channel 11)
Maximum output power (EIRP):
2.4 GHz band: 1.4 dBm
5 GHz band (5180 to 5320 MHz): 10.8 dBm
5 GHz band (5500 to 5825 MHz): 7.8 dBm
Authentication:
Open system, WPA2-PSK, WPA3-SAE
Padrões Bluetooth
Communication protocols:
Bluetooth Specification version 5.0
Operating frequency:
Bluetooth: 2402 to 2480 MHz
Bluetooth Low Energy: 2402 to 2480 MHz
Maximum output power (EIRP):
Bluetooth: -4.1 dBm
Bluetooth Low Energy: -5.6 dBm
Bateria
One EN-EL15c rechargeable Li-ion battery *
* EN-EL15b and EN-EL15a batteries can be used in place of the EN-EL15c. Note, however, that fewer pictures can be taken on a single charge than with the EN-EL15c. EH-7P charging AC adapters and EH-8P AC adapters can be used to charge EN-EL15c and EN-EL15b batteries only.
Battery pack
MB-N12 power battery packs (available separately) taking two EN-EL15c * batteries
* EN-EL15b and EN-EL15a batteries can be used in place of the EN-EL15c. Note, however, that fewer pictures can be taken on a single charge than with the EN-EL15c.
Adaptador CA
EH-7P charging AC adapters (available separately)
EH-8P AC adapters; requires UC-E25 USB cable (available separately)
EH-5d, EH-5c, and EH-5b AC adapters; requires EP-5B power connector (available separately)
Encaixe do tripé
0.635 cm (1/4 in., ISO 1222)
Dimensões (L x A x P)
Approx. 144 x 118.5 x 83 mm ( 5.7 x 4.7 x 3.3 in.)
Peso
Approx. 910 g
( 2 lb. 0.1 oz. )
with battery and memory card but without body cap and accessory shoe cover; approx. 820 g/1 lb. 13 oz. (camera body only)
Ambiente de funcionamento
Temperature: -10 °C to 40 °C (+14 °F to 104 °F)
Humidity: 85% or less (no condensation)
Acessórios incluídos
BS-1 accessory shoe cover (comes attached to camera), DK-33 rubber eyecup (comes attached to camera), BF-N1 body cap, EN-EL15c rechargeable Li-ion battery with terminal cover, MH-25a battery charger (comes with either an AC wall adapter or power cable of a type and shape that varies with the country or region of sale), HDMI/USB cable clip, AN-DC26 strap, UC-E24 USB cable
Notas
Unless otherwise stated, all measurements are performed in conformity with Camera and Imaging Products Association (CIPA) standards or guidelines.
All figures are for a camera with a fully-charged battery.
Throughout this document, “FX format” and “FX” are used in reference to an angle of view equivalent to that of a 35 mm format (“full frame”) camera and “DX format” and “DX” to an angle of view equivalent to that of an APS-C camera.
The sample images displayed on the camera and the images and illustrations in this document are for expository purposes only.
Nikon reserves the right to change the appearance and specifications of the hardware and software described in this document at any time and without prior notice. Nikon will not be held liable for damages that may result from any mistakes that this document may contain.
