| Designation |
Leica M11-D |
| Camera type |
Digital system camera with rangefinder |
| Dimensions |
139 x 38,5 x 80 mm |
| Weight |
approx. 539?g/457?g (with /without battery) |
| Sensor |
|
| Sensor size |
BSI CMOS sensor, pixel pitch: 3.76?µm, 35?mm: 9528?x?6328 pixels (60.3?MP) |
| Buffer memory |
3?GB
DNG™: 15 shots
JPG: > 100 shots
|
| Storage medium |
UHS-II (recommended), UHS-I, SD/SDHC/SDXC memory card (SDXC cards up to 2?TB), internal memory: 256?GB |
| Material |
Black: full-metal housing made of magnesium and aluminum, leatherette cover |
| Lens mount |
Leica M bayonet with additional sensor for 6-bit encoding |
| Operating conditions |
0°C to +40°C |
| Interfaces |
ISO accessory shoe with additional control contacts for Leica flash units and Leica Visoflex?2 viewfinder (optional accessory), USB 3.1 Gen1 Type-C |
| Tripod thread |
A 1/4 DIN 4503 (1/4”) with stainless steel in the base |
| Processor |
Leica Maestro series (Maestro III) |
| Filter |
RGB color filter, UV/IR filter, no low-pass filter |
| File formats |
DNG™ (raw data, loss-free compression), DNG + JPG, JPG (DCF, Exif 2.30) |
| Image resolution |
DNG™ |
|
L-DNG 60.3?MP 9528?x?6328 pixels
M-DNG 36.5?MP 7416?x?4928 pixels
S-DNG 18.4?MP 5272?x?3498 pixels
|
|
JPG |
|
L-JPG 60.1?MP 9504?x?6320 pixels
M-JPG 36.2?MP 7392?x?4896 pixels
S-JPG 18.2?MP 5248?x?3472 pixels
|
|
The entire sensor surface will always be used irrespective of format and resolution.
Digital Zoom 1.3x and 1.8x available (always based on L-DNG or L-JPG)
|
| File size |
DNG™ |
|
L-DNG approx. 70–120?MB
M-DNG approx. 40–70?MB
S-DNG approx. 20–40?MB
|
|
JPG |
|
L-JPG approx. 15–30?MB
M-JPG approx. 9–18?MB
S-JPG approx. 5–9?MB
|
|
JPG:?depending on resolution and image content |
| Color depth |
DNG™: 14?bit, JPG: 8?bit |
| Color space |
sRGB |
| Viewfinder |
|
| Viewfinder |
Large, bright-line rangefinder with automatic parallax compensation, suitable for -0.5?dpt; optional corrective lenses available: -3 to +3?dpt |
| Display |
Four-digit digital display with items show on the top and bottom, Image field limiter: two lit frames: 35?mm + 135?mm, 28?mm + 90?mm, 50?mm + 75?mm (automatic switchover when lens is attached) |
| Parallax compensation |
The horizontal and vertical difference between viewfinder and lens is compensated automatically in line with the relevant focus setting. Congruence of viewfinder and actual image. The size of the bright-line frame matches the distance: at 2?m: the exact sensor size of approx. 23.9?x?35.8?mm
at infinity: (depending on focal length) approx. 7.3% (28?mm) to 18% (135?mm)
less than 2?m: less than sensor size at 2?m: the exact sensor size of approx. 23.9?x?35.8?mm
at infinity: (depending on focal length) approx. 7.3% (28?mm) to 18% (135?mm)
less than 2?m: less than sensor size
|
| Viewfinder magnification |
0.73x (all lenses) |
| Large-base rangefinder |
Split or superimposed image rangefinder shown as a bright field at the center of the viewfinder image |
| Shutter |
|
| Shutter type |
Electronically controlled focal plane shutter and electronic shutter function |
| Shutter speeds |
Mech. shutter: 60?min to 1/4000?s
Electro. shutter function: 60?s to 1/16000?s
Flash Synch: up to 1/180?s
Optional noise reduction via additional “black picture” (can be disabled)
|
| Shutter button |
Two-stage
(Step 1: activation of the camera electronics including exposure metering and exposure lock, Step 2: release)
|
| Self-timer |
Delay time: 2?s or 12?s |
| Drive Mode |
?Single
?Continuous - Low Speed (3?fps)
?Continuous - High Speed (4.5?fps)
?Interval shooting
?Exposure Bracketing
|
| Focusing |
|
| Focus range |
70?cm to 8 |
| Focus mode |
Manual (focus assist functions Magnification and Focus Peaking available) |
| Exposure |
|
| Exposure metering |
TTL (exposure metering through the lens), with working aperture |
| Metering principle |
Exposure metering is done by the image sensor for all exposure metering methods (in Live View mode and in rangefinder mode) |
| Exposure metering methods |
?Spot, Center-Weighted, Multi-Field, Highlight-Weighted |
| Exposure modes |
Aperture-priority mode (A): automatic shutter speed control with manual aperture preselection |
|
Manual (M): manual setting for shutter speed and aperture |
| Exposure compensation |
±3?EV in 1/3?EV increments |
| Automatic bracketing |
3 or 5 frames, graduations between shoots up to 3?EV, in 1/3?EV increments, additional optional exposure compensation: up to ±3?EV |
| ISO sensitivity range |
Auto ISO: ISO 64 (native) to ISO 50?000, also available in flash mode |
|
Manual: ISO?64 to ISO?50?000 |
| White balance |
Automatic (Auto), Default (Daylight?-?5200?K, Cloudy?-?6100?K, Shadow?-?6600?K, Tungsten?-?2950?K, HMI?-?5700?K, Fluorescent (warm)? -?3650?K, Fluorescent (cool)?-?5800?K, Flash?-?6600?K), manual metering (Gray card), manual color temperature setting (Color Temperature, 2000?K to 11,500?K) |
| Flash |
|
| Flash unit connector |
Via the accessory shoe |
| Metering principle |
Flash exposure metering is done by the image sensor for all exposure metering methods (in Live View mode and in rangefinder mode) |
| Flash sync time |
: 1/180?s, slower shutter speeds available, automatic switchover to TTL linear flash mode with HSS-compatible Leica system flash units if sync time is undercut |
| Flash exposure metering |
Using center-weighted TTL pre-flash metering with Leica flash units (SF?26, SF?40, SF?58, SF?60, SF?64) or with system-compatible flash units, remote controlled flash SF?C1 |
| Flash exposure compensation |
SF?40: ±2?EV in 1/2?EV increments
SF?60: ±2?EV in 1/3?EV increments
Other: ±3?EV in 1/3?EV increments
|
| Displays in flash mode (in the viewfinder only) |
Flash icon: connection of an external flash unit |
|
|
| Equipment |
|
| WLAN |
The Leica FOTOS app is required to use the WLAN function. The Leica app is available from the Apple App Store™ or the Google Play Store™. 2.4 GHz/5?GHz* dual band IEEE802.11 a/b/g/n/ac Wave2 WLAN (standard WLAN protocol), encryption method: WLAN-kompatible WPA™/WPA2™, access method: infrastructure mode |
| Wi-Fi |
5?GHz*
EU/US/CN
11a/n/ac: Channel 149–165, (5745–5825?MHz)
|
|
JP
11a/n/ac: Channel 36–48, (5180–5240?MHz)
|
|
EU/US/CN
JP
ROW
2.4?GHz
11b/g/n: Channel 1–11 (2412–2462?MHz)
|
| Bluetooth |
Bluetooth v4.2 BR/EDR/LE, BR/DR-channel 1?79, LE-channel 0?39 (2402–2480?MHz) |
| GPS |
Geotagging via Leica FOTOS app using Bluetooth |
| Power supply |
|
|
Rechargeable battery
(Leica BP-SCL7)
|
Li-Ion (Lithium-Polymer) rechargeable battery, rated voltage: 7.4?V / capacity: 1800?mAh, Charging voltage/current: DC 1000?mAh, 7.4?V, operating conditions: +10°C to +35°C (charging) / +0°C to +40°C (discharged), manufacturer: Fuji Electronics (Shenzhen) Co., Ltd. made in China
Approx. 700 shots (in accordance with CIPA Standard in rangefinder mode), up to approx. 1700 shots (Leica adapted shooting cycle)
|
| Charger (Leica BC-SCL7) - Optional accessories |
Input: USB-C DC 5?V, 2?A, output: DC 8.4?V, 1?A, operating conditions: +10°C to +35°C, manufacturer: Dee Van Enterprises Co., Ltd., made in China |
| Switching adapter (Leica ACA-SCL7) - Optional accessories |
Input: AC 110?V - 240?V ~ 50/60?Hz, 0.3?A, output: DC 5?V, 2?A, operating conditions: +10°C to +35°C, manufacturer: Dee Van Enterprises Co., Ltd., made in China |
| USB power supply |
When in standby mode or Off: USB charging function
When On: USB power supply and intermittent charging
|
